Practical Report: Design and Simulation of a 5 kVA step-down single phase Transformer Transformer specification:
5kVA,3300Vto 220 V . Requirements: Technical Report Format (Cover Page, abstract, contents page, introduction, body, conclusion, IEEE Referencing etc) Discussion on transformer operation (Faraday's law, Lenz Law, transformer equations etc), components (windings, core etc). Calculations (Primary and secondary, number of turns, conductor size, core size etc) 5 kVA transformer simulation on Multi Sim. Simulation testing under the following loads (no load, full load,
(1)/(1)load, half load,
(1)/(4)load) Using an oscilloscope show the primary and secondary, voltage and current for each test and discuss observations Record data using the observation table below and analyse data Plot load vs efficiency, discuss and analyse data Plot load vs voltage regulation, discuss and analyse data \table[[Load,Primary Voltage
V_(1)(V),Primary Current I (A),Primary Wattmeter
W_(1)(W),Secondary Voltage
V_(2)(V),Secondary Current
I_(2)(A),Secondary Wattmeter
W_(1)(W),Regulation
%,Efficiency],[,,,,,,,,],[,,,,,,,,]]
