3. (10 pts) Using either regular graph paper or isometric graph paper (see scanned copy file in homework folder if you want to use it), draw by hand the isometric view shown by the 2 orthographic views in exercise 8.10 E., Oakes, Engineering Your Future, 9th Edition (page 260) 1. Use graph paper (either regular, oblique or isometric) to draw a neat 3D object - ( 2 pts) 2. Correct proportional shape - (1 pt) 3. Base cylinder - (2 pts) 4. Top cylinder - (2 pts) 5. Shows crosshairs for the circle (1 pts) 6. Shows negative cylinder (pipe) - (2 pt) 2. (10 pts) Using either regular graph paper or isometric graph paper (see scanned copy file in homework folder if you want to use it), draw by hand the isometric view shown by the 2 orthographic views in exercise \( 8.10 \) c., Oakes, Engineering Your Future, 9th Edition (page 260) 1. Use graph paper (either regular, oblique isometric) to draw a neat 3D object \( -(2 \) pts) 2. Correct proportional shape (1 pt) 3. Shows taper correctly (2 pts) 4. Shows a hole in correct location - (2 pts) 5. Shows crosshairs for the circle (2 pts) 6. Inside of hole not shown (1 pt)
