(Solved): 7-) The hydraulic cylinder AB exerts a force F of constant magnitude 2.5 kN directed from A to B as ...



7-) The hydraulic cylinder

AB

exerts a force

F

of constant magnitude 2.5 kN directed from

A

to

B

as the engine is elevated. Determine the moment of

F

about the point

C

as a function of

\theta

for the range

0<=\theta <=90\deg

. What is the weight

w

of the engine if the combined moment about

C

of the force

F

and weight

W

for

\theta

=30\deg

is equal to zero?
