(Solved): discrete math 1. Draw logic circuit diagram for the given Boolean expression using logic gates (AND, ...

1. Draw logic circuit diagram for the given Boolean expression using logic gates (AND, OR, NOT, NAND, NOR gates) without simplifying.the expression. \[ \overline{(A+B \bar{C})}(\bar{B}+\overline{A C})+\bar{A}+\overline{B C} \] 2. Simplified Boolean expression is = 3. Draw simplified logic gate circuit diagaram using minimum number of gates. Simplify the Boolean expression. \[ \overline{(\overline{\bar{A} \bar{C}}+\bar{B} \bar{C})+(\bar{B}+\bar{C} \bar{A})}= \]
